Model

F-500

F-800

F-1000

F-1300

F-1600

Type

Triplex single acting

Triplex single acting

Triplex single acting

Triplex single acting

Triplex single acting

Rated Power

373kw
500HP

596kw
800HP

735kw
1000HP

969kw
1300HP

1193kw
1600HP

Rated Speed

165 SPM

140 SPM

140 SPM

120 SPM

120 SPM

Stroke(mm/inch)

190/7 1/2″

254/10″

254/10″

305/12″

305/12″

Max.Liner Dia.

170/6 3/4″

170/6 3/4″

170/6 3/4″

180/7″

180/7″

Gear Type

Herringbone

Herringbone

Herringbone

Herringbone

Herringbone

Valve Pot

API-5#

API-6#

API-6#

API-7#

API-7#

Gear Ratio

4.286:1

4.207:1

4.207:1

4.206:1

4.206:1

Suction Inlet

203/8″

305/12″

305/12″

305/12″

305/12″

Discharge Inlet

4″Flange
5000 psi

5″Flange
5000 psi

5″Flange
5000 psi

5”Flange
5000 psi

5″Flange
5000 psi

Lubrication

Forced&
Splash

Forced&
Splash

Forced&
Splash

Forced&
Splash

Forced&
Splash

Max. Pressure

27.2Mpa
3945 psi

34.5Mpa
5000 psi

34.5Mpa
5000 psi

34.5Mpa
5000 psi

35Mpa
5080 psi

Overall Size(in)

144*106*86

163*89*70

163*89*70

174*121*78

181*129*106

Weight(kg)

9770

18790

18790

24572

24791
